Here's What These 7 Nest Thermostat Error Codes Mean

Using a Nest thermostat is one of the best ways to perfect the everyday schedule of your HVAC system. This smart thermostat can learn your preferences and automatically make adjustments. But as you might expect, it won’t work well or at all if you see an error code show up. The specific error code offers useful information about the root of the problem, something a trained technician can use to offer solutions that much sooner.

Listed below are seven of the most likely error codes you may discover on your Nest thermostat. We’ll review the basics of each error code on top of how you might address it and the projected cost to do so. Keep in mind that while the price will ultimately be dependent on the specific Nest model, you can expect to pay around $75-$200 for repairs. This should also cover travel and labor costs along with any specific components required to complete repairs.

e298 – Critical

This critical error code is limited to the latest models of the Nest thermostat and is displayed when the power is disconnected from the system. Because this is a critical power error, the thermostat will switch to the backup battery system. The error message will remain on display until the issue is resolved.

Losing power to your Nest thermostat can be for numerous reasons. The wiring may have disconnected or become damaged, or a disconnection might have happened further along in the electrical system. This may be the circuit breaker, fuse box or system switch. A knowledgeable technician should inspect electrical connections and wiring until they find the source of the problem.

e294 – Critical

Critical error code e294 shows up when your Nest thermostat’s wiring needs to be reconfigured. More specifically, the technician should reconfigure the R wire. They’ll first complete a factory reset of your thermostat to ensure it’s not simply a software problem. If that doesn’t work, they’ll check the wiring diagram of the thermostat and begin inspecting connectors.

They’ll detach the power and progressively look at each wire, ensuring they are fully attached into the connector with the proper amount of uncovered copper. After they pinpoint the damaged connector, it can be exchanged for a new one.

e195 – Critical

This critical error code can appear when the weather outside is particularly hot. The HVAC system can shut down and stop giving power to your Nest thermostat. When this problem persists, the backup battery in your thermostat depletes and the thermostat will eventually shut down. In the event the breakers are on, you can examine a few other places before consulting a professional technician.

Since this error can consume your thermostat’s battery, the first step may be providing enough power to find out if this specific error code is what you’re working with. You can disconnect the thermostat from its base and provide power through a USB cable. If it presents error code 195, you may continue to visually check components such as the wiring as well as your air conditioner’s air filter or drainage system. If you struggle to detect anything wrong with these components, it will likely be best to get in touch with a pro.

e103 – Critical

Another critical error code, e103 signifies an electrical malfunction with your Nest thermostat. More specifically, e103 can refer to an overcurrent problem, which means the wiring is experiencing more power than what is safe and normal. This will sometimes stem from the breaker box, an error from the control board or thanks to a faulty connection in the thermostat. A technician can meticulously inspect and test the Nest’s electrical system to understand where the power is surging or why the thermostat believes there’s an overcurrent problem.

n260

Although this error code isn’t critical, it could still stop you from using the Nest thermostat how you prefer to. Error code n260 pertains to the lack of a C wire or Nest Power Connector, as not having one can block your Nest from receiving adequate power. You can examine the Nest’s C connector for the presence of a C wire and modify the wiring itself if there is. If not, you need a Nest Power Connector.

Due to installation of a Nest Power Connector, you may notice error code E297 show up. This can be dealt with by updating your thermostat in Settings -> Software -> Update. If the Power Connector has already been installed, you’ll instead have to update the wiring info in the app from Settings -> Thermostat -> Wiring -> Update wiring.

e104 – Critical

Just like error code e103, e104 is a critical error that’s the result of an overcurrent. If excess power is transported using the Nest’s wiring, it may damage internal components and may even be a fire hazard. If you see this error code show up on your Nest thermostat and want to guard against electrical damage, it’s recommended to shut the power off as soon as you can. You can then get a hold of a professional technician with the appropriate experience detecting and fixing electrical issues.

e73 – Critical

When your thermostat displays error code e73, it signifies that the Rc wire is not receiving power.

This will sometimes be as easy as the breaker being switched off, but it may also be a problem with the wiring. After shutting off the power to your HVAC system and thermostat, you can visually check the wires to make sure they’re not loose or damaged. If nothing seems to be out of place, it’s a good idea to speak with a local professional.
